Description:

Mid-sized X-Torq® tree care saw. It´s a lightweight powerful chainsaw for pruning in parks as well as vineyards and fruit orchards.

The low weight and well-balanced saw body makes it very easy to work with.

Specifications:

Engine

• Cylinder Displacement: 35.2 cm³
• Output Shaft Power: 2.01 hp
• Torque (Max): 1.57 Nm @ 7,500 rpm
• Chain Speed at Max Power: 62.3 ft/s
• Clutch Engagement Speed (±120): 4,700 rpm
• Electrode Gap: 0.03 in
• Idling Speed: 2,900 rpm
• Ignition Module Air Gap: 0.02 in
• Maximum Power Speed: 10,000 rpm
• Oil Pump Capacity (Max): 9 ml/min
• Oil Pump Capacity (Min): 3 ml/min
• Oil Pump Type: Automatic
• Spark Plug: NGK CMR6H

Equipment

• Recommended Bar Length (Min/Max): 12 in / 14 in
• Pitch: 3/8" mini
• Chain Type: H37
• Bar Length: 14 in (35 cm)
• Sprocket Type: Spur 6
• Gauge: .050"

Dimensions

• Weight (Excl. Cutting Equipment): 7.5 lbs

Sound and Noise

• Sound Pressure Level at Operator's Ear: 103 dB(A)
• Sound Power Level (Guaranteed LWA): 114 dB(A)
• Sound Power Level (Measured): 112 dB(A)

Vibration

• Vibration Level (Rear Handle): 3.9 m/s²
• Vibration Level (Front Handle): 3.6 m/s²

Lubricant

• Oil Tank Volume: 0.36 US pint
• Lubricant Type: Husqvarna 2-stroke or equivalent at 50:1

Emissions

• Exhaust Emissions (CO₂ EU V): 860 g/kWh
