Description:

Save on storage space with the small riding mower design of the Troy-Bilt® TB30B riding mower. Ideal for smaller or gated yards, this riding mower has a 30" deck that will fit through most standard-size gates. Easily adjust your mowing speed with a 6-speed, Shift-on-the-Go™ transmission.

Features:

• 10.5 HP*/344cc Briggs & Stratton® engine designed for reliable starting
• 30" side-discharge steel cutting deck is designed to fit through gates 36" wide or larger and is an ideal choice for small or gated yards up to 1/2 acre.
• 6-speed Shift On The Go™ transmission has a dash panel control that is easy to see and adjust
• Space-saving design makes the TB30B riding mower easy to store in garages and sheds
• Help keep your lawn healthy and return nutrients into the soil by using the included mulch plug and help avoid thatch
• Small Riding Mower

Specifications:

Engine

• Engine Brand: Briggs & Stratton®
• Engine Model: Power Built
• Engine Model Number: 21R707-0152
• Engine Displacement: 344 cc
• Engine Output: 10.5 HP
• Starter Type: Electric
• Engine Start: Ignition Key
• Fuel Tank Capacity: 1.3 gal. US (4.92 L)
• Cylinders: Single
• Engine Oil Capacity: 1.5 qt. US (1.42 L)
• Lubrication: Fully pressurized
• Charging System: 3 amp regulated
• Fuel Gauge: No
• Governor: Mechanical
• Choke: Choke-a-matic
• Air Filter: Dual element
• Oil Filter: No
• Fuel Delivery: Carburetor

Battery

• Battery: 135 CCA
• Battery Type: AGM (Absorbent Glass Mat)
• Battery Voltage: 12V

Drive System

• Transmission: Troy-Bilt
• Forward Speed: 4.25 MPH (6.7 km/h)
• Reverse Speed: 2 MPH (3.2 km/h)
• Drive System: CVT (Continuously Variable Transmission)
• Transmission Control: 6-Speed Hand Lever
• Transmission Housing: Aluminum

Cutting Deck

• Deck Cutting Width: 30 in
• Deck Wash: No
• Deck Material: 14-gauge steel
• Deck Engagement (PTO): Manual
• Deck Construction: Stamped
• Blade(s): 1
• Deck Lift: Hand lever
• Cutting Height Range: 1.5" - 4"
• Deck Positions: 5

Chassis

• Frame: Robotically welded
• Turning Radius: 18"
• Bumper: No
• Rear Tow Hitch: Yes
• Corrosion Protection: Yes
• Front Pivot Bar: 14-gauge steel

Controls & Comfort

• Cruise Control: No
• Brakes: Disc
• Seat Type: Mid-back
• Armrests: No
• Seat Adjustment: Knob
• Floor Mats: Integral

Wheels

• Bearing Type: Poly Bushing
• Rear Tires: 16" x 6.5" - 8"
• Front Tires: 13" x 5" - 6"
• Tire Tread: Turf Saver

Additional Features

• Mulch Kit: Included
• Headlight(s): No
• Cup Holder: Yes
• Operator Presence System: Yes

Model & Warranty

• Model Number: 13AC26JDA23
• Residential Warranty: 2-year limited
• Frame Warranty: 2-year limited
• Front Axle Warranty: 2-year limited
• Deck Shell Warranty: 2-year limited
• Commercial Warranty: No
